Page 89 - Valparaiso, IN U.S. 30 Corridor Plan
P. 89
Adopted July 25, 2011
Plan
0' 60'
Wood or High Density
Wood or High Density Urethane Finial Structure,
Urethane Finial Structure, w/ Lit Logo Panels
w/ Lit Logo Panels
Natural Stone Veneer
Natural Stone Veneer Stone or Precast Cap
Existing
Stone or Precast Cap Concrete
Arch Structure Brick Veneer
Brick Veneer
Existing Conc. Existing
Wingwall Concrete
Arch Structure
Existing Conc.
Wingwall
North Washington Street North Washington Street
Elevation - looking north Section - looking west
Highway 30 Corridor Plan
Washington Street Railroad Bridge Refined Details
0' 8'
March 23, 2011
39
A-5
